Temperatur-Signalwandler HDTW-Serie Der Signalwandler der HDTW-Serie isoliert, wandelt und verteilt Thermoelement- (TC) und Widerstandsthermometer-Signale (RTD) in standardisierte Strom- oder Spannungssignale. Zusätzlich ist auch ein 1:1-Ausgang (direkte Weiterleitung) möglich. Dank dreifacher galvanischer Trennung zwischen Eingang, Ausgang und Versorgungsspannung bietet das Gerät höchste Stabilität, Störsicherheit und Zuverlässigkeit für den Einsatz in industriellen Automatisierungsumgebungen. Die Wandler sind mit intelligenter Online-Selbstdiagnose ausgestattet, arbeiten mit niedrigem Energieverbrauch, schneller Reaktion und hervorragenden Temperatureigenschaften. Sie eignen sich ideal zur Integration in DCS, SPS/PLC, SCADA und Messgeräte. Vorteile auf einen Blick Unterstützt Thermoelemente (K, J, T, B, S, R, N, E, WRe u.a.) Unterstützt RTDs (Pt100, Pt1000, Cu50, Cu100, BA1, BA2 u.a.) Galvanische Isolation zwischen Eingang, Ausgang und Stromversorgung Selbstdiagnose für stabile und sichere Signalübertragung Hohe Genauigkeit: ±0,1% F.S. Sehr geringer Temperaturdrift: ≤40 ppm/°C Schnelle Reaktion: ≤500 ms Flexibel: Strom- und Spannungsausgänge oder 1:1-Ausgang (TC/RTD) Für DIN-Schiene geeignet Industriequalität nach IEC61326-1 (EMV) Technische Spezifikationen Kategorie Details Modellreihe HDTW Genauigkeit ±0,1 % F.S. (bei 25°C ± 2°C) Reaktionszeit ≤500 ms Temperaturdrift ≤40 ppm/°C Ausgangsripple <5 mV Eingangssignale (TC) K, E, S, B, J, T, R, N, WRe3/25, WRe5/26 u.a. Eingangssignale (RTD) Pt100, Pt1000, Cu50, Cu100, BA1, BA2 u.a. Ausgangssignale 4-20mA; 0-20mA; 0-5V; 0-10V; 1:1 Thermoelement; 1:1 RTD Lastwiderstand Stromausgang ≤600 Ω (bei 4-20mA); ≤1 kΩ (bei ±10mA) Lastwiderstand Spannungsausg. ≥1 MΩ (0-5V); ≥2 MΩ (0-10V) Versorgungsspannung DC 18–32V   Leistungsaufnahme DC 24V: 0,7W (1in1out) / 1,3W (2in2out)   Isolation ≥2500 VAC, 1 min, 1 mA Isolationswiderstand ≥100 MΩ Kanalkonfigurationen 1in/1out, 1in/2out, 2in/2out Betriebstemperatur -20°C bis +60°C Schutzklasse IP20 (für Schaltschrankmontage) Abmessung:   110mm x 117mm x 17 mm   Lieferumfang: 1 x Temperatur-Signalwandler HDTW (nach Auswahl)

Read more less

Product description: PLC control module EC311-CPU2A310G1616D from LicOS Discover the powerful PLC control module EC311-CPU2A310G1616D, specially designed for automation systems with RS485 communication. Product Name PLC control module Model EC311-CPU2A310G1616D fire LicOS Place of Origin Condition 100% Original Series EC300 series Product Function Complete the execution of user program and logic control. Application Small and medium-sized PLC applications, such as process control, edge data acquisition, logic control, etc. Core Points 1. Support IEC61131-3 programming language (LD, FBD, IL, ST, SFC, CFC). 2. The CPU module supports a variety of industrial field buses, such as CAN bus, RS485 bus, industrial Ethernet bus, etc. 3.The CPU module supports a variety of industrial fieldbus protocols: CANopen, Modbus TCP master-slave, Modbus RTU/ASCII master-slave, Profinet/IO master-slave, EtherNet/IP, EtherCAT, etc. 4. Can communicate with the host computer through multiple network protocols: support MQTT protocol and OPC UA Server protocol. 5. 16m of program storage space, 32m of data storage space, 51m of power-off data retention and 32g of expandable storage space. 6. Instruction speed of 4 ns/basic instruction. 7. CPU supports Webvisu (Web version HMI). 8. Network information can be configured through the Web. 9.The standard backplane bus is integrated locally, and the body supports up to 16 GL100 I/O modules (16 * 32 = 512 points), and the head and tail refresh time is less than 5ms. 10. 16 racks can be extended via fieldbus. Technical consulting support Yes Warranty 1 year Product Feature 1. Ethernet speed reaches 10m/100Mbps self-adaptation. 2. A standard backplane bus is integrated locally. The body supports up to 16 I/O modules (16 * 32 = 512 points), and the head and tail refresh time is less than 5ms. 3. The body integrates 16-channel digital input (source/drain type) and 16-channel digital output (drain type). 4. Maximum capacity of IO point: 4096 digital channels and 1024 analog channels. 5. The switch network port can be configured as Modbus TCP or Profinet, EtherNet/IP according to the configuration. 6. It can indicate the normal operation of the program, the stop of the program, the system error indication and the bus status indication through the CPU panel. Communication Port ★3 independent RS485:, Modbus RTU/ASCII master/slave protocol, free protocol. ★1-way CAN bus. ★2-way Ethernet interface RJ45. Network Type ★1.Profinet ★2.Modbus TCP ★3.EtherNET/IP ★4.MQTT ★5.OPC ​​UA Server ★6.EterCAT Product model EC310-CPU1A310G1616D EC311-CPU2A310G1616D EC312-CPU3A310G1616D Main frequency of processor Memory Used in programs 16M 16M 16M 16M For data 32M + 1M power-down holdover 32m + 51m power-down holdover 32M + 1M power-down holdover Expandable memory 32G, SD card pluggable 32G, SD card pluggable 32G, SD card pluggable Storage mode Nand Flash permanent storage, no battery backup required. Programming mode IEC61131-3 Programming Language (LD/FBD/IL/ST/SFC/CFC) Program execution mode Compile and execute Instruction processing speed 4 ns/Basic Instruction 4 ns/Basic Instruction 4 ns/Basic Instruction Maximum capacity of IO point Remote IO site 64 64 64 Number of I/O modules 1024 1024 1024 CPU body module integrated IO input Number of channels 16 16 16 Contact type Source/Drain Input with High Speed ​​Input Interrupt Function Source/Drain Input with High Speed ​​Input Interrupt Function Source/Drain Input with High Speed ​​Input Interrupt Function CPU body module integrated IO output Number of channels 16 16 16 16 Contact type Drain type output Drain type output Drain type output Communication interface RS485 2 2 2 2 RS422 0 0 0 0 RS232 1 1 1 1 CAN 1 1 1 1 RJ45 1 2 3 Communication protocol EtherNet √ √ √ √ EtherCAT × √ √ √ profinet √ √ √ √ MQTT √ √ √ √ OPC UA Server √ √ √ √ Modbus TCP √ √ √ √ Canopic √ √ √ √ Modbus RTU/ASCLL √ √ √ √ Free agreement √ √ √ √ Network transmission √ √ √ √ EtherCAT motion control parameters / / / / WebVisu √ √ √ √ Supply voltage 24VDC(-15%~20%) 24VDC(-15%~20%) 24VDC(-15%~20%) 24VDC(-15%~20%) Scope of delivery : 1 x module

Read more less

Single-Channel Frequency Input Safety Barrier HD-506 The Frequency safety barrier HD-506 is used for safe separation and signal transmission between potentially explosive areas (zone 0, 1, 2) and the safe zone. The device converts Frequency pulse signals (0.1Hz–100kHz) into a standardized output signal (e.g. 4–20mA or 0–10V) around. Thanks to galvanic isolation between input, output and supply voltage ensures maximum safety and reliability. Online error diagnosis and PC programming options, the barrier can be flexibly adapted. Certified according to [Ex ia Ga] IIC (NEPSI), this device is ideal for applications in the Process automation, chemical, petrochemical, energy and manufacturing industries . Advantages Safe signal transmission between Ex area (Zone 0–2) and safe area Supports frequency input signals up to 100kHz Converts signals into 4–20mA, 0–10V, 0–5V or 1–5V to Galvanic isolation between Input, output and supply Error self-diagnosis for reliable operation Ex ia IIC certification for maximum safety in potentially explosive areas Compact design (only 12.7mm wide) for DIN rail mounting Technical data category Details Model series HD-506 Supply voltage 18–32VDC (with reverse polarity protection) Power consumption ≤0.8W (Single), ≤1.3W (Dual) Input signal Frequency pulse signal Frequency range 0.1Hz – 100kHz Pulse width >5 μs Input resistance ≥3 kΩ Signal trigger Low: 0–1V, High: 4–30V Distribution voltage 24VDC, ≥16V @ 20mA Output signals 4–20mA, 1–5V, 0–5V, 0–10V, others Max. load ≤550Ω (at 4–20mA) accuracy ±0.1% FS (25°C ±2°C) Temperature drift 40 ppm/°C Reaction time <500 ms Insulation voltage ≥2500V AC (intrinsically safe), ≥1500V AC (non-intrinsically safe) Insulation resistance ≥100 MΩ Operating temperature -20°C to +60°C Dimensions (W H D) 12.7mm × 110mm × 118.9mm Certification NEPSI, Ex ia IIC, Zone 0/1/2, T4-T6 Scope of delivery : 1 x piece
